Lenovo ThinkStation Intel XEON E3-1270 10GB RAM 1.5TB HDD 24" Monitor
LENOVO ThinkStation E30
Intel® Xeon® E3-1270 v2
SPECIFICATIONS
Processor
3.50 GHZ, 5GT/s DMI
8MB Cache
DDR3-1333/1600
Turbo, HT
69W Energy Saving
RAM
10GB (DDR3 ECC RAM 1600 MHz)
- 2 x 4GB
- 1 x 2GB
HDD
1TB SATA, 7200rpm
500GB SATA, 7200rpm
Chipset
Intel C216
Graphic Card
NVIDIA Quadro 600 1GB
Video Resolution
1920 x 1200 (16777216 colors)
Optical Drive
Bluray Combo
Front Ports
2 x High speed USB 2.0
1 x Headphone out
1 x Mic In
Rear Ports
4 x High Speed USB 3.
2 x High Speed USB 2.0
2 x RJ45 Gigabit Ethernet
1 x eSATA
1 x Serial
1 x Headphone out
1 x Mic In
1 x Line In
2 x IEEE1394 FireWIre 400 (4-pin connector)
2 x Display port
1 x VGA port
1 x DVI Port
Accessories & Monitor
1 x Keyboard and Mouse
1 x 24" Thinkvision monitor with 3 USB ports
1 x DVI Cable
1 x USB Cable (To connect CPU and Monitor)
Warranty
3 Months Warranty
Internal Details
4 x SATA
1 x SATA / eSATA 2 (300MB/s)
4 x Memory slots
- ECC DDR3 SDRAM and Non ECC DDR3 SDRAM supported
- Optional RAM configuration : 1GB, 2GB, 4GB uDIMM
- Maximum Capability : UDIMM : PC3-12800 (1600MHz)
- Maximum DIMM Size : UDIMM: up to 16GB
Audio : Integrated Realtek Audio ALC662-VC, Built in speaker
Networking : Intel® 82579 Integrated Gigabit Ethernet, TP Link Gigabit Ethernet
Expension Bays
2 x 5.25" Accessible Total
1 x 3.5 " Accessible Bays
2 x 3.5" Non-Accessible Bays (for HDD)
Slots
1-Lane PCI-E 2.0 - Half Length (Open)
16-Lane PCI-E 2.0 - Full Length (Video)
PCI v2.3 - Full Length (Modem/IEEE 1394)
PCI v2.3 - Full Length (Modem/IEEE 1394)
